Nichicon UCD1C220MCL6GS
- Mfg. Part Number
- UCD1C220MCL6GS
- Manufacturer
- Nichicon
- Product Category
- Aluminum Capacitors
- Brief Description
- CAP ALUM 22UF 20% 16V SMD
- Datasheet Download
- UCD1C220MCL6GS.pdf
Availability of UCD1C220MCL6GS
Available Quantity
7020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.07384
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of UCD1C220MCL6GS, we specialize in Nichicon all series electronic components. UCD1C220MCL6GS can be shipped within 24 hours after order. If you have any demands for UCD1C220MCL6GS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- UCD1C220MCL6GS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
UCD1C220MCL6GS
| Internal Part Number | EIS-UCD1C220MCL6GS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Capacitors | |
| Family | Aluminum Capacitors | |
| Series | CD | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 22µF | |
| Tolerance | ±20% | |
| Voltage Rating | 16V | |
| ESR (Equivalent Series Resistance) | - | |
| Lifetime @ Temp. | 2000 Hrs @ 105°C | |
| Operating Temperature | -55°C ~ 105°C | |
| Type | - | |
| Applications | General Purpose | |
| Ripple Current | 90mA | |
| Impedance | 1.35 Ohm | |
| Lead Spacing | - | |
| Size / Dimension | 0.157" Dia (4.00mm) | |
| Height - Seated (Max) | 0.240" (6.10mm) | |
| Surface Mount Land Size | 0.169" L x 0.169" W (4.30mm x 4.30mm) | |
| Mounting Type | Surface Mount | |
| Package / Case | Radial, Can - SMD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | UCD1C220MCL6GS | |
| Related Links | UCD1C22, UCD1C220MCL6GS Datasheet, Nichicon Distributor | |
