Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
Internal Part Number | EIS-UPD70F3454GC(R)-8EA-A | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
Standard Package | 1 | |
Category | Integrated Circuits (ICs) | |
Family | Embedded - Microcontrollers | |
Series | V850E/Ix3 | |
Packaging | Tray | |
Core Processor | V850ES | |
Core Size | 32-Bit | |
Speed | 64MHz | |
Connectivity | CSI, EBI/EMI, I²C, UART/USART | |
Peripherals | DMA, LVD, PWM, WDT | |
Number of I/O | 56 | |
Program Memory Size | 256KB (256K x 8) | |
Program Memory Type | FLASH | |
EEPROM Size | - | |
RAM Size | 12K x 8 | |
Voltage - Supply (Vcc/Vdd) | 3.5 V ~ 5.5 V | |
Data Converters | A/D 10x12b, 8x10b | |
Oscillator Type | External | |
Operating Temperature | -40°C ~ 85°C | |
Package / Case | 100-LQFP | |
Supplier Device Package | * | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | UPD70F3454GC(R)-8EA-A | |
Related Links | UPD70F3454, UPD70F3454GC(R)-8EA-A Datasheet, Renesas Electronics America Distributor |
