Microsemi Commercial Components USB50824C-AE3/TR13
- Mfg. Part Number
- USB50824C-AE3/TR13
- Manufacturer
- Microsemi Commercial Components
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 24VWM 57VC 8SOIC
- Datasheet Download
- USB50824C-AE3/TR13.pdf
Availability of USB50824C-AE3/TR13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.97200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of USB50824C-AE3/TR13, we specialize in Microsemi Commercial Components all series electronic components. USB50824C-AE3/TR13 can be shipped within 24 hours after order. If you have any demands for USB50824C-AE3/TR13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- USB50824C-AE3/TR13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
USB50824C-AE3/TR13
| Internal Part Number | EIS-USB50824C-AE3/TR13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 2 | |
| Voltage - Reverse Standoff (Typ) | 24V | |
| Voltage - Breakdown (Min) | 26.7V | |
| Voltage - Clamping (Max) @ Ipp | 57V | |
| Current - Peak Pulse (10/1000µs) | 5A (8/20µs) | |
| Power - Peak Pulse | 500W | |
| Power Line Protection | No | |
| Applications | Ethernet | |
| Capacitance @ Frequency | 3pF @ 1MHz | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | USB50824C-AE3/TR13 | |
| Related Links | USB50824C, USB50824C-AE3/TR13 Datasheet, Microsemi Commercial Components Distributor | |
USB50824C-AE3/TR13 Details Description
