Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
Internal Part Number | EIS-V150C24T150BL | |
Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Design Resources | Maxi/Mini/Micro Design Guide, Appl Manual | |
Standard Package | 1 | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Series | MICRO | |
Packaging | Bulk | |
Type | Isolated Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 100V | |
Voltage - Input (Max) | 200V | |
Voltage - Output 1 | 24V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 6.25A | |
Power (Watts) - Manufacture Series | 150W | |
Voltage - Isolation | 3kV (3000V) | |
Features | OVP, UVLO | |
Mounting Type | Through Hole | |
Package / Case | Quarter Brick | |
Size / Dimension | 2.28" L x 1.45" W x 0.65" H (57.9mm x 36.8mm x 16.5mm) | |
Operating Temperature | -40°C ~ 100°C | |
Efficiency | 87.7% | |
Power (Watts) - Max | 150W | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | V150C24T150BL | |
Related Links | V150C2, V150C24T150BL Datasheet, Vicor Corporation Distributor |
