Vicor Corporation V300C5H100BG3
- Mfg. Part Number
- V300C5H100BG3
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 5V 100W
- Datasheet Download
- V300C5H100BG3.pdf
Availability of V300C5H100BG3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 230.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V300C5H100BG3, we specialize in Vicor Corporation all series electronic components. V300C5H100BG3 can be shipped within 24 hours after order. If you have any demands for V300C5H100BG3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V300C5H100BG3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V300C5H100BG3
| Internal Part Number | EIS-V300C5H100BG3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Maxi/Mini/Micro Design Guide, Appl Manual | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | MICRO | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 180V | |
| Voltage - Input (Max) | 375V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) - Manufacture Series | 100W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OVP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Quarter Brick | |
| Size / Dimension | 2.28" L x 1.45" W x 0.65" H (57.9mm x 36.8mm x 16.5mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 81.5% | |
| Power (Watts) - Max | 100W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V300C5H100BG3 | |
| Related Links | V300C5, V300C5H100BG3 Datasheet, Vicor Corporation Distributor | |
V300C5H100BG3 Details Description
