Vicor Corporation V48C48C75BF3
- Mfg. Part Number
- V48C48C75BF3
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 48V 75W
- Datasheet Download
- V48C48C75BF3.pdf
Availability of V48C48C75BF3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 113.10000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V48C48C75BF3, we specialize in Vicor Corporation all series electronic components. V48C48C75BF3 can be shipped within 24 hours after order. If you have any demands for V48C48C75BF3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V48C48C75BF3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V48C48C75BF3
| Internal Part Number | EIS-V48C48C75BF3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Maxi/Mini/Micro Design Guide, Appl Manual | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | MICRO | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 48V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 1.56A | |
| Power (Watts) - Manufacture Series | 75W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OVP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Quarter Brick | |
| Size / Dimension | 2.28" L x 1.45" W x 0.54" H (57.9mm x 36.8mm x 13.7mm) | |
| Operating Temperature | -20°C ~ 100°C | |
| Efficiency | 87.9% | |
| Power (Watts) - Max | 75W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V48C48C75BF3 | |
| Related Links | V48C48, V48C48C75BF3 Datasheet, Vicor Corporation Distributor | |
V48C48C75BF3 Details Description
