ASSMANN WSW Components V5220L
- Mfg. Part Number
- V5220L
- Manufacturer
- ASSMANN WSW Components
- Product Category
- Thermal - Heat Sinks
- Brief Description
- HEATSINK ALUM ANOD TO-220
- Datasheet Download
- V5220L.pdf
Availability of V5220L
Available Quantity
5205 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.79520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V5220L, we specialize in ASSMANN WSW Components all series electronic components. V5220L can be shipped within 24 hours after order. If you have any demands for V5220L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V5220L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V5220L
| Internal Part Number | EIS-V5220L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | WSW Components Line of Board-Level Transistor Heat Sink Overview | |
| Standard Package | 250 | |
| Category | Fans, Thermal Management | |
| Family | Thermal - Heat Sinks | |
| Series | - | |
| Type | Board Level | |
| Package Cooled | TO-220 | |
| Attachment Method | Bolt On | |
| Shape | Rectangular, Fins | |
| Length | 1.181" (30.00mm) | |
| Width | 1.260" (32.00mm) | |
| Diameter | - | |
| Height Off Base (Height of Fin) | 0.787" (19.99mm) | |
| Power Dissipation @ Temperature Rise | - | |
| Thermal Resistance @ Forced Air Flow | - | |
| Thermal Resistance @ Natural | 8°C/W | |
| Material | Aluminum | |
| Material Finish | Black Anodized | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V5220L | |
| Related Links | V52, V5220L Datasheet, ASSMANN WSW Components Distributor | |
