ST VB325SP13TR
- Mfg. Part Number
- VB325SP13TR
- Manufacturer
- ST
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC COIL DRIVER PAR 10POWERSO
- Datasheet Download
- VB325SP13TR.pdf
Availability of VB325SP13TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VB325SP13TR, we specialize in ST all series electronic components. VB325SP13TR can be shipped within 24 hours after order. If you have any demands for VB325SP13TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VB325SP13TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VB325SP13TR
| Internal Part Number | EIS-VB325SP13TR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VB325SP View All Specifications | |
| Standard Package | 600 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | VIPower™ | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | Low Side | |
| Output Type | Bipolar | |
| Interface | Parallel | |
| Voltage - Load | 30V (Max) | |
| Voltage - Supply (Vcc/Vdd) | 4.5 V ~ 5.5 V | |
| Current - Output (Max) | 10A | |
| Rds On (Typ) | - | |
| Input Type | Non-Inverting | |
| Features | Status Flag | |
| Fault Protection | Over Temperature | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | PowerSO-10 Exposed Bottom Pad | |
| Supplier Device Package | 10-PowerSO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VB325SP13TR | |
| Related Links | VB325, VB325SP13TR Datasheet, ST Distributor | |
VB325SP13TR Details Description
