Vishay Semiconductor/Diodes Division VB40120C-E3/8W
- Mfg. Part Number
- VB40120C-E3/8W
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 120V TO263
- Datasheet Download
- VB40120C-E3/8W.pdf
Availability of VB40120C-E3/8W
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.55750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VB40120C-E3/8W, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. VB40120C-E3/8W can be shipped within 24 hours after order. If you have any demands for VB40120C-E3/8W, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VB40120C-E3/8W Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VB40120C-E3/8W
| Internal Part Number | EIS-VB40120C-E3/8W | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Functions & Parameters of the “Simplest” Semiconductor | |
| Standard Package | 800 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | TMBS® | |
| Packaging | Tape & Reel (TR) | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 120V | |
| Current - Average Rectified (Io) (per Diode) | 20A | |
| Voltage - Forward (Vf) (Max) @ If | 880mV @ 20A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 500µA @ 120V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-263AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VB40120C-E3/8W | |
| Related Links | VB40120, VB40120C-E3/8W Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
