ST VIPER06XSTR
- Mfg. Part Number
- VIPER06XSTR
- Manufacturer
- ST
- Product Category
- PMIC - AC DC Converters, Offline Switchers
- Brief Description
- IC OFFLINE SWITCH PWM 10-SSOP
- Datasheet Download
- VIPER06XSTR.pdf
Availability of VIPER06XSTR
Available Quantity
7520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.48000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VIPER06XSTR, we specialize in ST all series electronic components. VIPER06XSTR can be shipped within 24 hours after order. If you have any demands for VIPER06XSTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VIPER06XSTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VIPER06XSTR
| Internal Part Number | EIS-VIPER06XSTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VIPER06 View All Specifications | |
| Product Training Modules | Smart Grid Solutions: Smart Grid Distribution/Smart Meters High Voltage Offline Converters | |
| Featured Product | VIPer™Plus Converters | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Series | VIPer™ plus | |
| Packaging | Tape & Reel (TR) | |
| Output Isolation | Either | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 800V | |
| Topology | Buck, Flyback | |
| Voltage - Start Up | 13V | |
| Voltage - Supply (Vcc/Vdd) | 11.5 V ~ 23.5 V | |
| Duty Cycle | 70% | |
| Frequency - Switching | 30kHz | |
| Power (Watts) | 8W | |
| Fault Protection | Current Limiting, Open Loop, Over Temperature | |
| Control Features | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 10-SOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 10-SSO | |
| Mounting Type | Surface Mount | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VIPER06XSTR | |
| Related Links | VIPER, VIPER06XSTR Datasheet, ST Distributor | |
