Vishay/Vitramon VJ0402D9R1CXBAP
- Mfg. Part Number
- VJ0402D9R1CXBAP
- Manufacturer
- Vishay/Vitramon
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 9.1PF 100V NP0 0402
- Datasheet Download
- VJ0402D9R1CXBAP.pdf
Availability of VJ0402D9R1CXBAP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.19752
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VJ0402D9R1CXBAP, we specialize in Vishay/Vitramon all series electronic components. VJ0402D9R1CXBAP can be shipped within 24 hours after order. If you have any demands for VJ0402D9R1CXBAP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VJ0402D9R1CXBAP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VJ0402D9R1CXBAP
| Internal Part Number | EIS-VJ0402D9R1CXBAP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | VJ HIFREQ | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 9.1pF | |
| Tolerance | ±0.25pF | |
| Voltage - Rated | 100V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | RF, Microwave, High Frequency | |
| Ratings | - | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.040" L x 0.020" W (1.02mm x 0.51mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.024" (0.61mm) | |
| Lead Spacing | - | |
| Features | High Q, Low Loss | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VJ0402D9R1CXBAP | |
| Related Links | VJ0402D, VJ0402D9R1CXBAP Datasheet, Vishay/Vitramon Distributor | |
VJ0402D9R1CXBAP Details Description
