Vishay/Vitramon VJ0805D1R3CXPAP
- Mfg. Part Number
- VJ0805D1R3CXPAP
- Manufacturer
- Vishay/Vitramon
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 1.3PF 250V NP0 0805
- Datasheet Download
- VJ0805D1R3CXPAP.pdf
Availability of VJ0805D1R3CXPAP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.23176
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VJ0805D1R3CXPAP, we specialize in Vishay/Vitramon all series electronic components. VJ0805D1R3CXPAP can be shipped within 24 hours after order. If you have any demands for VJ0805D1R3CXPAP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VJ0805D1R3CXPAP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VJ0805D1R3CXPAP
| Internal Part Number | EIS-VJ0805D1R3CXPAP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | VJ HIFREQ | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 1.3pF | |
| Tolerance | ±0.25pF | |
| Voltage - Rated | 250V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | RF, Microwave, High Frequency | |
| Ratings | - | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.057" (1.45mm) | |
| Lead Spacing | - | |
| Features | High Q, Low Loss | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VJ0805D1R3CXPAP | |
| Related Links | VJ0805D, VJ0805D1R3CXPAP Datasheet, Vishay/Vitramon Distributor | |
VJ0805D1R3CXPAP Details Description
