Eaton (formerly Cooper Bussmann) VP5-0155TR-R
- Mfg. Part Number
- VP5-0155TR-R
- Manufacturer
- Eaton (formerly Cooper Bussmann)
- Product Category
- Arrays, Signal Transformers
- Brief Description
- INDUCT ARRAY 6 COIL 9.9UH SMD
- Datasheet Download
- VP5-0155TR-R.pdf
Availability of VP5-0155TR-R
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.22690
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VP5-0155TR-R, we specialize in Eaton (formerly Cooper Bussmann) all series electronic components. VP5-0155TR-R can be shipped within 24 hours after order. If you have any demands for VP5-0155TR-R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VP5-0155TR-R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VP5-0155TR-R
| Internal Part Number | EIS-VP5-0155TR-R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SEPIC Converter | |
| PCN Assembly/Origin | Multiple Devices 31/Aug/2013 Coiltronics Magnetics Facility 31/Aug/2013 | |
| Standard Package | 115 | |
| Category | Inductors, Coils, Chokes | |
| Family | Arrays, Signal Transformers | |
| Series | VERSA-PAC® | |
| Packaging | Tape & Reel (TR) | |
| Number of Coils | 6 | |
| Inductance - Connected In Series | - | |
| Inductance - Connected In Parallel | - | |
| Tolerance | - | |
| Current Rating - Parallel | - | |
| Current Rating - Series | - | |
| Current Saturation - Parallel | - | |
| Current Saturation - Series | - | |
| DC Resistance (DCR) - Parallel | - | |
| DC Resistance (DCR) - Series | - | |
| Shielding | Unshielded | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.827" L x 1.122" W (21.00mm x 28.50mm) | |
| Height | 0.425" (10.80mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VP5-0155TR-R | |
| Related Links | VP5-01, VP5-0155TR-R Datasheet, Eaton (formerly Cooper Bussmann) Distributor | |
