Hirose Electric Co Ltd W.FL-R-SMT-1(10)
.jpg)
- Mfg. Part Number
- W.FL-R-SMT-1(10)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Coaxial Connectors (RF)
- Brief Description
- CONN W.FL JACK STR 50 OHM SMD
- Datasheet Download
- W.FL-R-SMT-1(10).pdf
Availability of W.FL-R-SMT-1(10)
Available Quantity
31020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.62400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of W.FL-R-SMT-1(10), we specialize in Hirose Electric Co Ltd all series electronic components. W.FL-R-SMT-1(10) can be shipped within 24 hours after order. If you have any demands for W.FL-R-SMT-1(10), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- W.FL-R-SMT-1(10) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
W.FL-R-SMT-1(10)
| Internal Part Number | EIS-W.FL-R-SMT-1(10) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | W.FL Series 1.4mm Height Coaxial Connector U.FL and W.FL Series Connectors | |
| Standard Package | 2,000 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Connector Style | W.FL | |
| Connector Type | Jack, Male Pin | |
| Contact Termination | Solder | |
| Shield Termination | Solder | |
| Impedance | 50 Ohm | |
| Mounting Type | Surface Mount | |
| Cable Group | - | |
| Fastening Type | Snap-On | |
| Frequency - Max | 6GHz | |
| Features | - | |
| Housing Color | Black | |
| Ingress Protection | - | |
| Body Material | Phosphor Bronze | |
| Body Finish | Silver | |
| Center Contact Material | Brass | |
| Center Contact Plating | Gold | |
| Dielectric Material | Liquid Crystal Polymer (LCP) | |
| Voltage Rating | - | |
| Operating Temperature | -40°C ~ 90°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | W.FL-R-SMT-1(10) | |
| Related Links | W.FL-R-S, W.FL-R-SMT-1(10) Datasheet, Hirose Electric Co Ltd Distributor | |
