3M W153208-2020-TH
- Mfg. Part Number
- W153208-2020-TH
- Manufacturer
- 3M
- Product Category
- Rectangular Connectors - Headers, Receptacles, Female Sockets
- Brief Description
- Connector Receptacle 8 Position 0.079" (2.00mm) Gold Surface Mount
- Datasheet Download
- W153208-2020-TH.pdf
Availability of W153208-2020-TH
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of W153208-2020-TH, we specialize in 3M all series electronic components. W153208-2020-TH can be shipped within 24 hours after order. If you have any demands for W153208-2020-TH, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- W153208-2020-TH Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
W153208-2020-TH
| Internal Part Number | EIS-W153208-2020-TH | |
| Lead Free Status / RoHS Status | Vendor undefined / Vendor undefined | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 800 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
| Series | 1532 | |
| Packaging | Tray | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 8 | |
| Number of Positions Loaded | All | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.079" (2.00mm) | |
| Mounting Type | Surface Mount | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | Board Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 15µin (0.38µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | W153208-2020-TH | |
| Related Links | W153208, W153208-2020-TH Datasheet, 3M Distributor | |
W153208-2020-TH Details Description
