Omron Automation & Safety WLCA2-LD
- Mfg. Part Number
- WLCA2-LD
- Manufacturer
- Omron Automation & Safety
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SW LIMIT SPDT 10A ROLLR LEVER
- Datasheet Download
- WLCA2-LD.pdf
Availability of WLCA2-LD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of WLCA2-LD, we specialize in Omron Automation & Safety all series electronic components. WLCA2-LD can be shipped within 24 hours after order. If you have any demands for WLCA2-LD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- WLCA2-LD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
WLCA2-LD
| Internal Part Number | EIS-WLCA2-LD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | WL Series Dec/2014 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | WL | |
| Packaging | Bulk | |
| Circuit | SPDT-DM/DB | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC), 6A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Side Rotary, Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Screw Terminal | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | LED Indicator | |
| Operating Force, Torque | 1360gf | |
| Release Force | 227gf | |
| Pretravel | 15° | |
| Differential Travel | 12° | |
| Overtravel | 30° | |
| Operating Position | - | |
| Mechanical Life | 15,000,000 Cycles | |
| Electrical Life | 750,000 Cycles | |
| Operating Temperature | -10°C ~ 80°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | WLCA2-LD | |
| Related Links | WLCA, WLCA2-LD Datasheet, Omron Automation & Safety Distributor | |
