Exar Corporation XR77129ELB-F
- Mfg. Part Number
- XR77129ELB-F
- Manufacturer
- Exar Corporation
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC CTRLR BUCK PWM 44TQFN
- Datasheet Download
- XR77129ELB-F.pdf
Availability of XR77129ELB-F
Available Quantity
5397 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.95003
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of XR77129ELB-F, we specialize in Exar Corporation all series electronic components. XR77129ELB-F can be shipped within 24 hours after order. If you have any demands for XR77129ELB-F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- XR77129ELB-F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
XR77129ELB-F
| Internal Part Number | EIS-XR77129ELB-F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tray | |
| Number of Outputs | 4 | |
| Frequency - Max | 1.23MHz | |
| Duty Cycle | - | |
| Voltage - Supply | 6 V ~ 40 V | |
| Buck | Yes | |
| Boost | No | |
| Flyback | No | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 44-WFQFN Exposed Pad | |
| Supplier Device Package | 44-TQFN (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | XR77129ELB-F | |
| Related Links | XR7712, XR77129ELB-F Datasheet, Exar Corporation Distributor | |
