NKK Switches YB226CWSPW01
- Mfg. Part Number
- YB226CWSPW01
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 3A 125V
- Datasheet Download
- YB226CWSPW01.pdf
Availability of YB226CWSPW01
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 25.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of YB226CWSPW01, we specialize in NKK Switches all series electronic components. YB226CWSPW01 can be shipped within 24 hours after order. If you have any demands for YB226CWSPW01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- YB226CWSPW01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
YB226CWSPW01
| Internal Part Number | EIS-YB226CWSPW01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Pushbutton Switches | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | YB2 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 3A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Plunger for Cap | |
| Color - Actuator/Cap | - | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Square - 21.00mm² | |
| Operating Temperature | -25°C ~ 70°C | |
| Mechanical Life | 200,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | YB226CWSPW01 | |
| Related Links | YB226C, YB226CWSPW01 Datasheet, NKK Switches Distributor | |
YB226CWSPW01 Details Description
