TDK Corporation YNA18B2C0G105M
- Mfg. Part Number
- YNA18B2C0G105M
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 1UF 4V X5R 0603
- Datasheet Download
- YNA18B2C0G105M.pdf
Availability of YNA18B2C0G105M
Available Quantity
17020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.18375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of YNA18B2C0G105M, we specialize in TDK Corporation all series electronic components. YNA18B2C0G105M can be shipped within 24 hours after order. If you have any demands for YNA18B2C0G105M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- YNA18B2C0G105M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
YNA18B2C0G105M
| Internal Part Number | EIS-YNA18B2C0G105M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | C Series General Applications SEAT, CCV, and TVCL Design Tools Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| Featured Product | CER Series Controlled ESR MLCCs | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | YNA | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 1µF | |
| Tolerance | ±20% | |
| Voltage - Rated | 4V | |
| Temperature Coefficient | X5R | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 85°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0603 (1608 Metric) | |
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.035" (0.90mm) | |
| Lead Spacing | - | |
| Features | Controlled ESR | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | YNA18B2C0G105M | |
| Related Links | YNA18B2, YNA18B2C0G105M Datasheet, TDK Corporation Distributor | |
YNA18B2C0G105M Details Description
