Intersil ZL2103ALAFT
- Mfg. Part Number
- ZL2103ALAFT
- Manufacturer
- Intersil
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK PROG 3A SYNC 36QFN
- Datasheet Download
- ZL2103ALAFT.pdf
Availability of ZL2103ALAFT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZL2103ALAFT, we specialize in Intersil all series electronic components. ZL2103ALAFT can be shipped within 24 hours after order. If you have any demands for ZL2103ALAFT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZL2103ALAFT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZL2103ALAFT
| Internal Part Number | EIS-ZL2103ALAFT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 10/Jun/2015 | |
| Standard Package | 4,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Programmable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 14V | |
| Voltage - Output (Min/Fixed) | 0.6V | |
| Voltage - Output (Max) | 5V | |
| Current - Output | 3A | |
| Frequency - Switching | 200kHz ~ 1MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 36-VFQFN Exposed Pad | |
| Supplier Device Package | 36-QFN (6x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZL2103ALAFT | |
| Related Links | ZL210, ZL2103ALAFT Datasheet, Intersil Distributor | |
ZL2103ALAFT Details Description
