Molex Connector Corporation 0192120003
- Mfg. Part Number
- 0192120003
- Manufacturer
- Molex Connector Corporation
- Product Category
- Terminals - Wire Pin Connectors
- Brief Description
- CONN WIRE PIN TERM 18-22AWG
- Datasheet Download
- 0192120003.pdf
Availability of 0192120003
Available Quantity
9874 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.15136
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0192120003, we specialize in Molex Connector Corporation all series electronic components. 0192120003 can be shipped within 24 hours after order. If you have any demands for 0192120003, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0192120003 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0192120003
| Internal Part Number | EIS-0192120003 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 19212-0003 Cert of Compliance | |
| Featured Product | Solderless Terminals Interactive Guide | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Wire Pin Connectors | |
| Series | InsulKrimp™ | |
| Packaging | Bulk | |
| Pin Diameter | Circular - 0.078" (1.98mm) Dia | |
| Length - Pin | 0.390" (9.91mm) | |
| Length - Overall | 0.930" (23.62mm) | |
| Wire Gauge | 18-22 AWG | |
| Insulation Diameter | 0.145" (3.68mm) | |
| Insulation | Insulated | |
| Termination | Crimp | |
| Features | - | |
| Color | Red | |
| Contact Material | Copper | |
| Contact Finish | Tin | |
| Diameter - Barrel ID | 0.055" (1.40mm) | |
| Diameter - Barrel OD | - | |
| Material - Insulation | Poly-Vinyl Chloride (PVC) | |
| Length - Termination | 0.400" (10.16mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0192120003 | |
| Related Links | 01921, 0192120003 Datasheet, Molex Connector Corporation Distributor | |
