Molex Connector Corporation 0192210562
- Mfg. Part Number
- 0192210562
- Manufacturer
- Molex Connector Corporation
- Product Category
- Terminals - Ring Connectors
- Brief Description
- BCL-814-WP UNPLATED .594
- Datasheet Download
- 0192210562.pdf
Availability of 0192210562
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.37637
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0192210562, we specialize in Molex Connector Corporation all series electronic components. 0192210562 can be shipped within 24 hours after order. If you have any demands for 0192210562, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0192210562 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0192210562
| Internal Part Number | EIS-0192210562 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 192210562 Cert of Compliance | |
| Featured Product | Solderless Terminals Interactive Guide | |
| PCN Other | 19221, 19321, 19082 Series Supplier Change 03/Jul/2014 | |
| Standard Package | 250 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Ring Connectors | |
| Series | - | |
| Packaging | Bulk | |
| Terminal Type | Flat Sided, Tubular | |
| Stud/Tab Size | 1/4 Stud | |
| Thickness | 0.070" (1.78mm) | |
| Width - Outer Edges | 0.594" (15.09mm) | |
| Length - Overall | 1.313" (33.35mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 8 AWG | |
| Insulation | Non-Insulated | |
| Features | Heavy Duty | |
| Color | - | |
| Contact Material | Copper | |
| Contact Finish | - | |
| Insulation Diameter | - | |
| Material - Insulation | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0192210562 | |
| Related Links | 01922, 0192210562 Datasheet, Molex Connector Corporation Distributor | |
