Molex Connector Corporation 0386913802
- Mfg. Part Number
- 0386913802
- Manufacturer
- Molex Connector Corporation
- Product Category
- Terminal Blocks - Barrier Blocks
- Brief Description
- Connector Barrier Block Strip 2 Circuit 0.325" (8.26mm)
- Datasheet Download
- 0386913802.pdf
Availability of 0386913802
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.94500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0386913802, we specialize in Molex Connector Corporation all series electronic components. 0386913802 can be shipped within 24 hours after order. If you have any demands for 0386913802, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0386913802 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0386913802
| Internal Part Number | EIS-0386913802 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Terminal Block Plant Transfer 16/Dec/2014 | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Barrier Blocks | |
| Series | Beau™ 38691 | |
| Packaging | Bulk | |
| Terminal Block Type | Barrier Block | |
| Number of Circuits | 2 | |
| Number of Wire Entries | 2 | |
| Pitch | 0.325" (8.26mm) | |
| Number of Rows | 1 | |
| Current Rating | 20A | |
| Voltage Rating | 300V | |
| Wire Gauge | 12-22 AWG | |
| Top Termination | Screws with Captive Plate | |
| Bottom Termination | Wire Wrap | |
| Barrier Type | 3 Wall (Tri) | |
| Features | - | |
| Color | Black | |
| Terminal Screw Material | - | |
| Terminal Screw Finish | - | |
| Mounting Type | Chassis, Panel | |
| Operating Temperature | 110°C | |
| Material - Insulation | Thermoplastic | |
| Material Flammability Rating | UL94 V-0 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0386913802 | |
| Related Links | 03869, 0386913802 Datasheet, Molex Connector Corporation Distributor | |
