JST Sales America Inc. 03R-WPJV-1-SM(NN)
R-WPJV-1-SM(NN).jpg)
- Mfg. Part Number
- 03R-WPJV-1-SM(NN)
- Manufacturer
- JST Sales America Inc.
- Product Category
- Rectangular Connectors - Housings
- Brief Description
- CONN HOUSING RECEPT 3POS NAT 5MM
- Datasheet Download
- 03R-WPJV-1-SM(NN).pdf
Availability of 03R-WPJV-1-SM(NN)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.89424
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 03R-WPJV-1-SM(NN), we specialize in JST Sales America Inc. all series electronic components. 03R-WPJV-1-SM(NN) can be shipped within 24 hours after order. If you have any demands for 03R-WPJV-1-SM(NN), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 03R-WPJV-1-SM(NN) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
03R-WPJV-1-SM(NN)
| Internal Part Number | EIS-03R-WPJV-1-SM(NN) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | WPJ Connector | |
| Standard Package | 576 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Housings | |
| Series | WPJ | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 3 | |
| Pitch | 0.197" (5.00mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Contact Termination | Crimp | |
| Fastening Type | Latch Lock | |
| Color | Natural | |
| Features | JIS C 0920 Grade Level 7 | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 03R-WPJV-1-SM(NN) | |
| Related Links | 03R-WPJV, 03R-WPJV-1-SM(NN) Datasheet, JST Sales America Inc. Distributor | |
03R-WPJV-1-SM(NN) Details Description
