Molex Connector Corporation 0459858132
- Mfg. Part Number
- 0459858132
- Manufacturer
- Molex Connector Corporation
- Product Category
- Backplane Connectors - Specialized
- Brief Description
- CONN HEADER 8PWR 20SGL 2.36MM
- Datasheet Download
- 0459858132.pdf
Availability of 0459858132
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.84790
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0459858132, we specialize in Molex Connector Corporation all series electronic components. 0459858132 can be shipped within 24 hours after order. If you have any demands for 0459858132, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0459858132 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0459858132
| Internal Part Number | EIS-0459858132 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 0459858132 Cert of Compliance | |
| 3D Model | 45985-8132.stp0459858132 .pdf | |
| PCN Other | 45985 Series 21/May/2015 | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Series | EXTreme LPHPower™ 45985 | |
| Packaging | Tray | |
| Connector Usage | - | |
| Connector Type | Plug, Center Strip Contacts | |
| Connector Style | LPHPower | |
| Number of Positions | 28 | |
| Number of Positions Loaded | All | |
| Pitch | 0.050" (1.27mm) | |
| Number of Rows | 2 | |
| Number of Columns | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Contact Layout, Typical | 20 Signal, 8 Power | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Black | |
| Current Rating | - | |
| Material Flammability Rating | UL94 V-0 | |
| Operating Temperature | -40°C ~ 105°C | |
| Voltage Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0459858132 | |
| Related Links | 04598, 0459858132 Datasheet, Molex Connector Corporation Distributor | |
