FFF 10113947-A0C-20B
- Mfg. Part Number
- 10113947-A0C-20B
- Manufacturer
- FFF
- Product Category
- Backplane Connectors - Specialized
- Brief Description
- XCEDE LEFT 2PVH 6COL WK
- Datasheet Download
- 10113947-A0C-20B.pdf
Availability of 10113947-A0C-20B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.17829
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 10113947-A0C-20B, we specialize in FFF all series electronic components. 10113947-A0C-20B can be shipped within 24 hours after order. If you have any demands for 10113947-A0C-20B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 10113947-A0C-20B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
10113947-A0C-20B
| Internal Part Number | EIS-10113947-A0C-20B | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 120 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Series | XCede® | |
| Packaging | Tray | |
| Connector Usage | Backplane | |
| Connector Type | Header, Male Pins and Blades | |
| Connector Style | XCede®, Guide Left | |
| Number of Positions | - | |
| Number of Positions Loaded | All | |
| Pitch | - | |
| Number of Rows | - | |
| Number of Columns | 6 | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Contact Layout, Typical | 18 Differential Pairs | |
| Features | Key | |
| Contact Finish | Gold or Gold, GXT™ | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Gray | |
| Current Rating | - | |
| Material Flammability Rating | UL94 V-0 | |
| Operating Temperature | -55°C ~ 85°C | |
| Voltage Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 10113947-A0C-20B | |
| Related Links | 10113947, 10113947-A0C-20B Datasheet, FFF Distributor | |
