Honeywell Sensing and Productivity Solutions 12TW1-7E
- Mfg. Part Number
- 12TW1-7E
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 5A 125V
- Datasheet Download
- 12TW1-7E.pdf
Availability of 12TW1-7E
Available Quantity
5024 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 73.20000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 12TW1-7E, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. 12TW1-7E can be shipped within 24 hours after order. If you have any demands for 12TW1-7E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 12TW1-7E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
12TW1-7E
| Internal Part Number | EIS-12TW1-7E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | TW | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | Mom-Off-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Locking Lever | |
| Actuator Length | 29.46mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Turret | |
| Panel Cutout Dimensions | Circular - 12.40mm Dia | |
| Bushing Thread | 15/32-32 | |
| Ingress Protection | Environment Proof | |
| Features | - | |
| Actuator Material | - | |
| Electrical Life | - | |
| Operating Temperature | -65°C ~ 71°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 12TW1-7E | |
| Related Links | 12TW, 12TW1-7E Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
12TW1-7E Details Description
