Alpha Wire 1856 WG001
- Mfg. Part Number
- 1856 WG001
- Manufacturer
- Alpha Wire
- Product Category
- Single Conductor Cables (Hook-Up Wire)
- Brief Description
- HOOK-UP 20AWG WHT/GRN 1000'
- Datasheet Download
- 1856 WG001.pdf
Availability of 1856 WG001
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 211.77000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1856 WG001, we specialize in Alpha Wire all series electronic components. 1856 WG001 can be shipped within 24 hours after order. If you have any demands for 1856 WG001, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1856 WG001 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1856 WG001
| Internal Part Number | EIS-1856 WG001 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Basics of Wire and Cable | |
| Standard Package | 1 | |
| Category | Cables, Wires | |
| Family | Single Conductor Cables (Hook-Up Wire) | |
| Series | MIL-W-16878E/1 and MIL-W-76B Type LW, 1856 | |
| Cable Type | Hook-Up | |
| Wire Gauge | 20 AWG | |
| Conductor Strand | 7/28 | |
| Conductor Material | Copper, Tinned | |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | |
| Jacket (Insulation) Diameter | 0.058" (1.47mm) | |
| Jacket (Insulation) Thickness | 0.010" (0.25mm) | |
| Length | 1000' (304.8m) | |
| Voltage | 600V | |
| Operating Temperature | -55°C ~ 105°C | |
| Jacket Color | White, Green Stripe | |
| Ratings | - | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1856 WG001 | |
| Related Links | 1856 , 1856 WG001 Datasheet, Alpha Wire Distributor | |
