Central Semiconductor Corp 1N5256B TR
- Mfg. Part Number
- 1N5256B TR
- Manufacturer
- Central Semiconductor Corp
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 30V 500MW DO35
- Datasheet Download
- 1N5256B TR.pdf
Availability of 1N5256B TR
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09028
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1N5256B TR, we specialize in Central Semiconductor Corp all series electronic components. 1N5256B TR can be shipped within 24 hours after order. If you have any demands for 1N5256B TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1N5256B TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1N5256B TR
| Internal Part Number | EIS-1N5256B TR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Declaration of Compliance | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Voltage - Zener (Nom) (Vz) | 30V | |
| Tolerance | ±5% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 49 Ohm | |
| Current - Reverse Leakage @ Vr | 100nA @ 23V | |
| Voltage - Forward (Vf) (Max) @ If | 1.1V @ 200mA | |
| Operating Temperature | -65°C ~ 200°C | |
| Mounting Type | Through Hole | |
| Package / Case | DO-204AH, DO-35, Axial | |
| Supplier Device Package | DO-35 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1N5256B TR | |
| Related Links | 1N525, 1N5256B TR Datasheet, Central Semiconductor Corp Distributor | |
