E-Switch 200AWMSP5T1A1M2QE
- Mfg. Part Number
- 200AWMSP5T1A1M2QE
- Manufacturer
- E-Switch
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SPDT 3A 120V
- Datasheet Download
- 200AWMSP5T1A1M2QE.pdf
Availability of 200AWMSP5T1A1M2QE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.52640
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 200AWMSP5T1A1M2QE, we specialize in E-Switch all series electronic components. 200AWMSP5T1A1M2QE can be shipped within 24 hours after order. If you have any demands for 200AWMSP5T1A1M2QE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 200AWMSP5T1A1M2QE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
200AWMSP5T1A1M2QE
| Internal Part Number | EIS-200AWMSP5T1A1M2QE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 200A Series RoHS Cert of Compliance | |
| 3D Model | 200AWMSPxT1A1M2xE.stp | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 200A | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-Mom | |
| Current Rating | 3A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard Round | |
| Actuator Length | 10.16mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 50,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 200AWMSP5T1A1M2QE | |
| Related Links | 200AWMSP, 200AWMSP5T1A1M2QE Datasheet, E-Switch Distributor | |
