Bourns Inc. 2200HT-331-H-RC
- Mfg. Part Number
- 2200HT-331-H-RC
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 330UH 3.1A 180 MOHM TH
- Datasheet Download
- 2200HT-331-H-RC.pdf
Availability of 2200HT-331-H-RC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.47630
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2200HT-331-H-RC, we specialize in Bourns Inc. all series electronic components. 2200HT-331-H-RC can be shipped within 24 hours after order. If you have any demands for 2200HT-331-H-RC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2200HT-331-H-RC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2200HT-331-H-RC
| Internal Part Number | EIS-2200HT-331-H-RC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | Label Change 30/Jun/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 64 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 2200HT | |
| Packaging | Bulk | |
| Type | Toroidal | |
| Material - Core | Powdered Iron | |
| Inductance | 330µH | |
| Tolerance | ±15% | |
| Current Rating | 3.1A | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 180 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 200°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.950" Dia (24.13mm) | |
| Height - Seated (Max) | 0.550" (13.97mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2200HT-331-H-RC | |
| Related Links | 2200HT-, 2200HT-331-H-RC Datasheet, Bourns Inc. Distributor | |
