Amphenol RF 242100
- Mfg. Part Number
- 242100
- Manufacturer
- Amphenol RF
- Product Category
- Coaxial Connectors (RF) - Adapters
- Brief Description
- CONN ADAPT N JACK TO BNC JACK
- Datasheet Download
- 242100.pdf
Availability of 242100
Available Quantity
5135 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 13.02600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 242100, we specialize in Amphenol RF all series electronic components. 242100 can be shipped within 24 hours after order. If you have any demands for 242100, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 242100 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
242100
| Internal Part Number | EIS-242100 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) - Adapters | |
| Series | - | |
| Packaging | Bulk | |
| Adapter Type | Jack to Jack | |
| Adapter Series | BNC to N | |
| Center Gender | Female to Female | |
| Convert From (Adapter End) | N Jack, Female Socket | |
| Convert To (Adapter End) | BNC Jack, Female Socket | |
| Conversion Type | Between Series | |
| Impedance | 50 Ohm | |
| Style | Straight | |
| Mounting Type | Free Hanging (In-Line) | |
| Frequency - Max | 4GHz | |
| Ingress Protection | - | |
| Features | - | |
| Body Material | Brass | |
| Body Finish | Nickel | |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | |
| Center Contact Material | Phosphor Bronze | |
| Center Contact Plating | Gold | |
| Mating Cycles | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 242100 | |
| Related Links | 242, 242100 Datasheet, Amphenol RF Distributor | |
242100 Details Description
