Rohm Semiconductor 2SB1197KT146Q
- Mfg. Part Number
- 2SB1197KT146Q
- Manufacturer
- Rohm Semiconductor
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS PNP 32V 0.8A SOT-346
- Datasheet Download
- 2SB1197KT146Q.pdf
Availability of 2SB1197KT146Q
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.05491
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 2SB1197KT146Q, we specialize in Rohm Semiconductor all series electronic components. 2SB1197KT146Q can be shipped within 24 hours after order. If you have any demands for 2SB1197KT146Q, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 2SB1197KT146Q Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
2SB1197KT146Q
| Internal Part Number | EIS-2SB1197KT146Q | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Transistor Type | PNP | |
| Current - Collector (Ic) (Max) | 800mA | |
| Voltage - Collector Emitter Breakdown (Max) | 32V | |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 50mA, 500mA | |
| Current - Collector Cutoff (Max) | 500nA (ICBO) | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 120 @ 100mA, 3V | |
| Power - Max | 200mW | |
| Frequency - Transition | 200MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SMT3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 2SB1197KT146Q | |
| Related Links | 2SB119, 2SB1197KT146Q Datasheet, Rohm Semiconductor Distributor | |
2SB1197KT146Q Details Description
