Micro Commercial Components (MCC) 3SMAJ5936B-TP
- Mfg. Part Number
- 3SMAJ5936B-TP
- Manufacturer
- Micro Commercial Components (MCC)
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 30V 3W DO214AC
- Datasheet Download
- 3SMAJ5936B-TP.pdf
Availability of 3SMAJ5936B-TP
Available Quantity
12520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09840
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 3SMAJ5936B-TP, we specialize in Micro Commercial Components (MCC) all series electronic components. 3SMAJ5936B-TP can be shipped within 24 hours after order. If you have any demands for 3SMAJ5936B-TP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 3SMAJ5936B-TP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
3SMAJ5936B-TP
| Internal Part Number | EIS-3SMAJ5936B-TP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Diode Handling and Mounting | |
| Featured Product | Power Zeners in SMA & SMB Packages | |
| Standard Package | 7,500 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 30V | |
| Tolerance | ±5% | |
| Power - Max | 3W | |
| Impedance (Max) (Zzt) | 28 Ohm | |
| Current - Reverse Leakage @ Vr | 1µA @ 22.8V | |
| Voltage - Forward (Vf) (Max) @ If | 1.5V @ 200mA | |
| Operating Temperature | -55°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AC, SMA | |
| Supplier Device Package | DO-214AC (SMA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 3SMAJ5936B-TP | |
| Related Links | 3SMAJ5, 3SMAJ5936B-TP Datasheet, Micro Commercial Components (MCC) Distributor | |
3SMAJ5936B-TP Details Description
