Schurter 5130.2201
- Mfg. Part Number
- 5130.2201
- Manufacturer
- Schurter
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- MODULE PWR ENT 250V 16/20A SNAP
- Datasheet Download
- 5130.2201.pdf
Availability of 5130.2201
Available Quantity
5076 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.87060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 5130.2201, we specialize in Schurter all series electronic components. 5130.2201 can be shipped within 24 hours after order. If you have any demands for 5130.2201, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 5130.2201 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
5130.2201
| Internal Part Number | EIS-5130.2201 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 5130 Series.igs5130 Series.stp5130 Series.x_b5130 Series.dxf5130 Series.wrl | |
| PCN Packaging | Multiple Devices 20/Nov/2015 | |
| Standard Package | 20 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | 5130 | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C20 | |
| Connector Type | Receptacle, Male Blades | |
| Current - IEC | 16A | |
| Voltage - IEC | 250VAC | |
| Current - UL | 20A | |
| Voltage - UL | 250VAC | |
| Filter Type | Filtered (EMI, RFI) - Commercial, Medical | |
| Fuse | No | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination | Quick Connect - 0.250" (6.3mm) | |
| Switch Features | - | |
| Features | Shielded | |
| Fuse Holder, Drawer | - | |
| Panel Cutout Dimensions | Rectangular - 35.00mm x 27.00mm | |
| Panel Thickness | 0.031" ~ 0.118" (0.79mm ~ 3.00mm) | |
| Material Flammability Rating | UL94 V-0 | |
| Ingress Protection | IP40 | |
| Approvals | cULus, ENEC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 5130.2201 | |
| Related Links | 5130, 5130.2201 Datasheet, Schurter Distributor | |
