CTS Electronic Components 520M20CA20M0000
- Mfg. Part Number
- 520M20CA20M0000
- Manufacturer
- CTS Electronic Components
- Product Category
- Oscillators
- Brief Description
- OSC VCTCXO 20.000MHZ CSNWV SMD
- Datasheet Download
- 520M20CA20M0000.pdf
Availability of 520M20CA20M0000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.84005
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 520M20CA20M0000, we specialize in CTS Electronic Components all series electronic components. 520M20CA20M0000 can be shipped within 24 hours after order. If you have any demands for 520M20CA20M0000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 520M20CA20M0000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
520M20CA20M0000
| Internal Part Number | EIS-520M20CA20M0000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | 520 | |
| Packaging | Tape & Reel (TR) | |
| Type | VCTCXO | |
| Frequency | 20MHz | |
| Function | - | |
| Output | Clipped Sine Wave | |
| Voltage - Supply | 1.8V | |
| Frequency Stability | ±2ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Current - Supply (Max) | 2mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Height | 0.031" (0.80mm) | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 520M20CA20M0000 | |
| Related Links | 520M20C, 520M20CA20M0000 Datasheet, CTS Electronic Components Distributor | |
520M20CA20M0000 Details Description
