Vishay/BCcomponents 564R30GAQ12
- Mfg. Part Number
- 564R30GAQ12
- Manufacturer
- Vishay/BCcomponents
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 12PF 3KV RADIAL
- Datasheet Download
- 564R30GAQ12.pdf
Availability of 564R30GAQ12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.78120
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 564R30GAQ12, we specialize in Vishay/BCcomponents all series electronic components. 564R30GAQ12 can be shipped within 24 hours after order. If you have any demands for 564R30GAQ12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 564R30GAQ12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
564R30GAQ12
| Internal Part Number | EIS-564R30GAQ12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 250 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | Cera-Mite 564R | |
| Packaging | Bulk | |
| Capacitance | 12pF | |
| Tolerance | ±20% | |
| Voltage - Rated | 3000V (3kV) | |
| Temperature Coefficient | - | |
| Mounting Type | Through Hole | |
| Operating Temperature | -25°C ~ 105°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | Radial, Disc | |
| Size / Dimension | 0.331" Dia (8.40mm) | |
| Height - Seated (Max) | 0.520" (13.20mm) | |
| Thickness (Max) | - | |
| Lead Spacing | 0.252" (6.40mm) | |
| Features | - | |
| Lead Style | Straight | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 564R30GAQ12 | |
| Related Links | 564R3, 564R30GAQ12 Datasheet, Vishay/BCcomponents Distributor | |
