Grayhill, Inc. 56BSDP30-01SAJS
- Mfg. Part Number
- 56BSDP30-01SAJS
- Manufacturer
- Grayhill, Inc.
- Product Category
- Rotary Switches
- Brief Description
- ROTARY SWITCH ADJ
- Datasheet Download
- 56BSDP30-01SAJS.pdf
Availability of 56BSDP30-01SAJS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 18.43160
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 56BSDP30-01SAJS, we specialize in Grayhill, Inc. all series electronic components. 56BSDP30-01SAJS can be shipped within 24 hours after order. If you have any demands for 56BSDP30-01SAJS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 56BSDP30-01SAJS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
56BSDP30-01SAJS
| Internal Part Number | EIS-56BSDP30-01SAJS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | 56 | |
| Number of Positions | 2 ~ 3 | |
| Index Stops | Adjustable | |
| Number of Decks | 1 | |
| Number of Poles per Deck | 4 | |
| Circuit per Deck | 4P3T | |
| Contact Timing | Shorting (MBB) | |
| Current Rating | 200mA (AC/DC) | |
| Voltage Rating - AC | 115V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Screwdriver Slot | |
| Actuator Length | 3.18mm | |
| Angle of Throw | 30° | |
| Contact Material | Brass | |
| Contact Finish | Silver | |
| Mounting Type | Panel Mount, Through Hole | |
| Termination Style | PC Pin | |
| Features | Shaft and Panel Sealed | |
| Depth Behind Panel | 9.58mm | |
| Panel Cutout Dimensions | - | |
| Operating Force, Torque | 3.5 ~ 9 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 56BSDP30-01SAJS | |
| Related Links | 56BSDP3, 56BSDP30-01SAJS Datasheet, Grayhill, Inc. Distributor | |
