API Delevan 6016-056
- Mfg. Part Number
- 6016-056
- Manufacturer
- API Delevan
- Product Category
- Power Transformers
- Brief Description
- XFRMR LAMINATED 20VA THRU HOLE
- Datasheet Download
- 6016-056.pdf
Availability of 6016-056
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.97600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 6016-056, we specialize in API Delevan all series electronic components. 6016-056 can be shipped within 24 hours after order. If you have any demands for 6016-056, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 6016-056 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
6016-056
| Internal Part Number | EIS-6016-056 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 15 | |
| Category | Transformers | |
| Family | Power Transformers | |
| Series | 6016 | |
| Type | Laminated Core | |
| Voltage - Primary | 115V | |
| Voltage - Secondary (Full Load) | Parallel 28V, Series 56V | |
| Current - Output (Max) | Parallel 700mA, Series 350mA | |
| Primary Winding(s) | Single | |
| Secondary Winding(s) | Dual | |
| Center Tap | No | |
| Power - Max | 20 VA | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Size / Dimension | 57.15mm L x 47.63mm W | |
| Height - Seated (Max) | 36.50mm | |
| Voltage - Isolation | 2500Vrms | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 6016-056 | |
| Related Links | 6016, 6016-056 Datasheet, API Delevan Distributor | |
6016-056 Details Description
