Schurter 6200.4320
- Mfg. Part Number
- 6200.4320
- Manufacturer
- Schurter
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- MOD PWR ENTRY 1PL QC 2MM SNAP-IN
- Datasheet Download
- 6200.4320.pdf
Availability of 6200.4320
Available Quantity
5131 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.77900
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 6200.4320, we specialize in Schurter all series electronic components. 6200.4320 can be shipped within 24 hours after order. If you have any demands for 6200.4320, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 6200.4320 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
6200.4320
| Internal Part Number | EIS-6200.4320 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS, Connectors Products | |
| 3D Model | 6200, 6202, 6205 Series.igs6200, 6202, 6205 Series.step6200, 6202, 6205 Series.x_b6200, 6202, 6205 Series.dxf6200, 6202, 6205 Series.wrl | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | 6200 | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C14 | |
| Connector Type | Receptacle, Male Blades - Module | |
| Current - IEC | 10A | |
| Voltage - IEC | 250VAC | |
| Current - UL | 10A | |
| Voltage - UL | 250VAC | |
| Filter Type | Unfiltered - Commercial | |
| Fuse | Yes | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination | Quick Connect - 0.250" (6.3mm) | |
| Switch Features | - | |
| Features | - | |
| Fuse Holder, Drawer | Fuse Holder | |
| Panel Cutout Dimensions | Rectangular - 27.50mm x 31.50mm | |
| Panel Thickness | 0.079" (2.00mm) | |
| Material Flammability Rating | UL94 V-0 | |
| Ingress Protection | IP40 | |
| Approvals | CCC, CSA, ENEC, UL | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 6200.4320 | |
| Related Links | 6200, 6200.4320 Datasheet, Schurter Distributor | |
