TXC CORPORATION 9C-4.096MBBK-T
- Mfg. Part Number
- 9C-4.096MBBK-T
- Manufacturer
- TXC CORPORATION
- Product Category
- Crystals
- Brief Description
- Crystal 4.0960MHz 50ppm 20pF 150 Ohm -20°C - 70°C Surface Mount HC-49S
- Datasheet Download
- 9C-4.096MBBK-T.pdf
Availability of 9C-4.096MBBK-T
Available Quantity
6020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.16800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 9C-4.096MBBK-T, we specialize in TXC CORPORATION all series electronic components. 9C-4.096MBBK-T can be shipped within 24 hours after order. If you have any demands for 9C-4.096MBBK-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 9C-4.096MBBK-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
9C-4.096MBBK-T
| Internal Part Number | EIS-9C-4.096MBBK-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Crystals | |
| Series | 9C | |
| Packaging | Tape & Reel (TR) | |
| Type | MHz Crystal | |
| Frequency | 4.096MHz | |
| Frequency Stability | ±50ppm | |
| Frequency Tolerance | ±50ppm | |
| Load Capacitance | 20pF | |
| ESR (Equivalent Series Resistance) | 150 Ohm | |
| Operating Mode | Fundamental | |
| Operating Temperature | -20°C ~ 70°C | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Package / Case | HC-49S | |
| Size / Dimension | 0.449" L x 0.189" W (11.40mm x 4.80mm) | |
| Height | 0.161" (4.10mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 9C-4.096MBBK-T | |
| Related Links | 9C-4.09, 9C-4.096MBBK-T Datasheet, TXC CORPORATION Distributor | |
9C-4.096MBBK-T Details Description
