Omron Automation & Safety A16-AYA-2
- Mfg. Part Number
- A16-AYA-2
- Manufacturer
- Omron Automation & Safety
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 5A 125V
- Datasheet Download
- A16-AYA-2.pdf
Availability of A16-AYA-2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 34.24000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A16-AYA-2, we specialize in Omron Automation & Safety all series electronic components. A16-AYA-2 can be shipped within 24 hours after order. If you have any demands for A16-AYA-2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A16-AYA-2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A16-AYA-2
| Internal Part Number | EIS-A16-AYA-2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Multiple Devices Nameplate May/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | A16 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Square, Button | |
| Color - Actuator/Cap | Yellow | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP40 | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 16.00mm Dia | |
| Operating Temperature | -10°C ~ 55°C | |
| Mechanical Life | 200,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A16-AYA-2 | |
| Related Links | A16-, A16-AYA-2 Datasheet, Omron Automation & Safety Distributor | |
A16-AYA-2 Details Description
