Allegro MicroSystems, LLC A3906SES-T
- Mfg. Part Number
- A3906SES-T
- Manufacturer
- Allegro MicroSystems, LLC
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 20QFN
- Datasheet Download
- A3906SES-T.pdf
Availability of A3906SES-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A3906SES-T, we specialize in Allegro MicroSystems, LLC all series electronic components. A3906SES-T can be shipped within 24 hours after order. If you have any demands for A3906SES-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A3906SES-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A3906SES-T
| Internal Part Number | EIS-A3906SES-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 92 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | Bipolar | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (4) | |
| Interface | Parallel | |
| Technology | DMOS | |
| Step Resolution | 1, 1/2 | |
| Applications | Battery Powered | |
| Current - Output | 1A | |
| Voltage - Supply | 2.5 V ~ 9 V | |
| Voltage - Load | 2.5 V ~ 9 V | |
| Operating Temperature | -20°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-WFQFN Exposed Pad | |
| Supplier Device Package | 20-QFN (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A3906SES-T | |
| Related Links | A3906, A3906SES-T Datasheet, Allegro MicroSystems, LLC Distributor | |
A3906SES-T Details Description
