Sullins Connector Solutions ABE40DHBS
- Mfg. Part Number
- ABE40DHBS
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 80POS 1MM
- Datasheet Download
- ABE40DHBS.pdf
Availability of ABE40DHBS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 24.43500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABE40DHBS, we specialize in Sullins Connector Solutions all series electronic components. ABE40DHBS can be shipped within 24 hours after order. If you have any demands for ABE40DHBS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABE40DHBS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABE40DHBS
| Internal Part Number | EIS-ABE40DHBS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 40 | |
| Number of Positions | 80 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.039" (1.00mm) | |
| Features | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder, Staggered | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Contact Type | Hairpin Bellows | |
| Color | - | |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 150°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABE40DHBS | |
| Related Links | ABE4, ABE40DHBS Datasheet, Sullins Connector Solutions Distributor | |
