Abracon Corporation ABM8-26.000MHZ-10-1-U-T
.jpg)
- Mfg. Part Number
- ABM8-26.000MHZ-10-1-U-T
- Manufacturer
- Abracon Corporation
- Product Category
- Crystals
- Brief Description
- Crystal 26.0000MHz 10ppm 10pF 50 Ohm -10°C - 60°C Surface Mount 4-SMD, No Lead (DFN, LCC)
- Datasheet Download
- ABM8-26.000MHZ-10-1-U-T.pdf
Availability of ABM8-26.000MHZ-10-1-U-T
Available Quantity
57020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.51300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABM8-26.000MHZ-10-1-U-T, we specialize in Abracon Corporation all series electronic components. ABM8-26.000MHZ-10-1-U-T can be shipped within 24 hours after order. If you have any demands for ABM8-26.000MHZ-10-1-U-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABM8-26.000MHZ-10-1-U-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABM8-26.000MHZ-10-1-U-T
| Internal Part Number | EIS-ABM8-26.000MHZ-10-1-U-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | ABM8.pdfABM8.stp | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Crystals | |
| Series | ABM8 | |
| Packaging | Tape & Reel (TR) | |
| Type | MHz Crystal | |
| Frequency | 26MHz | |
| Frequency Stability | ±10ppm | |
| Frequency Tolerance | ±10ppm | |
| Load Capacitance | 10pF | |
| ESR (Equivalent Series Resistance) | 50 Ohm | |
| Operating Mode | Fundamental | |
| Operating Temperature | -10°C ~ 60°C | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | |
| Height | 0.031" (0.80mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABM8-26.000MHZ-10-1-U-T | |
| Related Links | ABM8-26.000, ABM8-26.000MHZ-10-1-U-T Datasheet, Abracon Corporation Distributor | |
ABM8-26.000MHZ-10-1-U-T Details Description
