Avago Technologies US, Inc. ACPL-827-000E
- Mfg. Part Number
- ACPL-827-000E
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISOLATOR 5KV 2CH TRANS 8DIP
- Datasheet Download
- ACPL-827-000E.pdf
Availability of ACPL-827-000E
Available Quantity
5691 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ACPL-827-000E, we specialize in Avago Technologies US, Inc. all series electronic components. ACPL-827-000E can be shipped within 24 hours after order. If you have any demands for ACPL-827-000E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ACPL-827-000E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ACPL-827-000E
| Internal Part Number | EIS-ACPL-827-000E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 2 | |
| Voltage - Isolation | 5000Vrms | |
| Current Transfer Ratio (Min) | 50% @ 5mA | |
| Current Transfer Ratio (Max) | 600% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 4µs, 3µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 70V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 50mA | |
| Vce Saturation (Max) | 200mV | |
| Operating Temperature | -30°C ~ 100°C | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ACPL-827-000E | |
| Related Links | ACPL-8, ACPL-827-000E Datasheet, Avago Technologies US, Inc. Distributor | |
