Analog ADM1075-2ACPZ-RL7
- Mfg. Part Number
- ADM1075-2ACPZ-RL7
- Manufacturer
- Analog
- Product Category
- PMIC - Hot Swap Controllers
- Brief Description
- IC HOT SWAP CTRLR -48V 28LFCSP
- Datasheet Download
- ADM1075-2ACPZ-RL7.pdf
Availability of ADM1075-2ACPZ-RL7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.39967
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADM1075-2ACPZ-RL7, we specialize in Analog all series electronic components. ADM1075-2ACPZ-RL7 can be shipped within 24 hours after order. If you have any demands for ADM1075-2ACPZ-RL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADM1075-2ACPZ-RL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADM1075-2ACPZ-RL7
| Internal Part Number | EIS-ADM1075-2ACPZ-RL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Assembly and Test Transfer LFCSP Devices 22/Oct/2013 Assembly/Test Site Revision F 06/Aug/2014 | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Hot Swap Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Hot Swap Controller, Monitor | |
| Number of Channels | 1 | |
| Internal Switch(s) | No | |
| Applications | -48V | |
| Features | Auto Retry, PMBus | |
| Programmable Features | Circuit Breaker, Current Limit, Fault Timeout, OVP, UVLO | |
| Voltage - Supply | -80 V ~ -35 V | |
| Current - Output (Max) | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply | 5.5mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-WFQFN Exposed Pad, CSP | |
| Supplier Device Package | 28-LFCSP-WQ (5x5) | |
| Feature Pins | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADM1075-2ACPZ-RL7 | |
| Related Links | ADM1075-, ADM1075-2ACPZ-RL7 Datasheet, Analog Distributor | |
ADM1075-2ACPZ-RL7 Details Description
