Honeywell Sensing and Productivity Solutions AML25GBF8CA01YG
- Mfg. Part Number
- AML25GBF8CA01YG
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 3A 125V
- Datasheet Download
- AML25GBF8CA01YG.pdf
Availability of AML25GBF8CA01YG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 98.10000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AML25GBF8CA01YG, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. AML25GBF8CA01YG can be shipped within 24 hours after order. If you have any demands for AML25GBF8CA01YG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AML25GBF8CA01YG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AML25GBF8CA01YG
| Internal Part Number | EIS-AML25GBF8CA01YG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | AML Series LED Appl Note | |
| Design Resources | AML/MML Series Tech Guide | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | AML25 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 3A (AC), 2A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 24V | |
| Actuator Type | Paddle | |
| Actuator Length | - | |
| Illumination | Illuminated | |
| Illumination Type, Color | LED, Green/Yellow | |
| Illumination Voltage (Nominal) | 24 VDC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
| Bushing Thread | - | |
| Ingress Protection | - | |
| Features | Diode Protection for LED | |
| Actuator Material | - | |
| Electrical Life | 25,000 Cycles | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AML25GBF8CA01YG | |
| Related Links | AML25GB, AML25GBF8CA01YG Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
AML25GBF8CA01YG Details Description
