Honeywell Sensing and Productivity Solutions AML34EBA4AA01
- Mfg. Part Number
- AML34EBA4AA01
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPST 15A 125V
- Datasheet Download
- AML34EBA4AA01.pdf
Availability of AML34EBA4AA01
Available Quantity
5024 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 28.65000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AML34EBA4AA01, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. AML34EBA4AA01 can be shipped within 24 hours after order. If you have any demands for AML34EBA4AA01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AML34EBA4AA01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AML34EBA4AA01
| Internal Part Number | EIS-AML34EBA4AA01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Electromechanical Switch Technology | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | AML34 | |
| Packaging | Bulk | |
| Circuit | SPST | |
| Switch Function | On-Off | |
| Current Rating | 15A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Actuator Arm, Cap Required | |
| Color - Actuator/Cap | - | |
| Actuator Marking | Varies by Cap | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
| Operating Temperature | - | |
| Mechanical Life | 25,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AML34EBA4AA01 | |
| Related Links | AML34E, AML34EBA4AA01 Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
