Bourns Inc. AMS22S5A1BHAFL126
- Mfg. Part Number
- AMS22S5A1BHAFL126
- Manufacturer
- Bourns Inc.
- Product Category
- Position Sensors - Angle, Linear Position Measuring
- Brief Description
- ROTARY NON-CONTACT ANALOG SENSOR
- Datasheet Download
- AMS22S5A1BHAFL126.pdf
Availability of AMS22S5A1BHAFL126
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 33.32500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AMS22S5A1BHAFL126, we specialize in Bourns Inc. all series electronic components. AMS22S5A1BHAFL126 can be shipped within 24 hours after order. If you have any demands for AMS22S5A1BHAFL126, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AMS22S5A1BHAFL126 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AMS22S5A1BHAFL126
| Internal Part Number | EIS-AMS22S5A1BHAFL126 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Sensors, Transducers | |
| Family | Position Sensors - Angle, Linear Position Measuring | |
| Series | AMS22S | |
| For Measuring | Rotary Position | |
| Technology | Hall Effect | |
| Rotation Angle - Electrical, Mechanical | 10° ~ 260°, Continuous | |
| Linear Range | - | |
| Output | Analog Voltage | |
| Output Signal | Counterclockwise Increase | |
| Actuator Type | Flatted Shaft | |
| Linearity | ±0.5% | |
| Resistance (Ohms) | - | |
| Resistance Tolerance | - | |
| Voltage - Supply | 5V | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AMS22S5A1BHAFL126 | |
| Related Links | AMS22S5A, AMS22S5A1BHAFL126 Datasheet, Bourns Inc. Distributor | |
AMS22S5A1BHAFL126 Details Description
